Nissan Rogue (T33) 2021-Present Service Manual: Periodic Maintenance :: Recommended Fluids and Lubricants

Fluids and Lubricants

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedures described elsewhere in this manual

Fluid type				Capacity (approximate)			Recommended Fluids/Lubricants
				Metric Measure	US Measure	Imperial Measure
Fuel				55.0	14-1/2 gal	12-1/8 gal	Unleaded gasoline with an octane rating of at least 87 AKI (RON 91)
Engine oil Drain and refill		With oil filter change		4.7	5 qt	4-1/8 qt	Genuine "NISSAN Motor Oil 0W-20 SP" (or equivalent) is recommended. If the above motor oil (or engine oil) is not available, a synthetic 0W-20 GF-6A SP motor oil (or engine oil) may be used. Damage caused by the use of motor oil (or engine oil) other than as recommended is not covered under NISSAN’s New Nissan Ariya Vehicle Limited Warranty. For additional information, see "Engine Oil Recommendations".
		Without oil filter change		4.6	4-7/8 qt	4 qt
Dry engine (engine overhaul)				5.6	5-7/8 qt	4-7/8 qt
Engine coolant (with reservoir tank)				8.5	9 qt	7-1/2 qt	Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent
Reservoir tank				0.8	7/8 qt	3/4 qt
Intercooler coolant (with reservoir tank)				3	3-1/8 qt	2-5/8 qt
Reservoir tank				0.5	1/2 qt	1/2 qt
CVT fluid				9.7	10‐1/4 qt	8-3/4 qt	Genuine NISSAN CVT Fluid NS-3 NISSAN recommends using Genuine NISSAN CVT Fluid NS-3 (or equivalent) ONLY in NISSAN CVTs. Do not mix with other fluids. Using fluids that are not equivalent to Genuine NISSAN CVT Fluid NS-3 may damage the CVT. Damage caused by the use of fluids other than as recommended is not covered under NISSAN’s New Nissan Ariya Vehicle Limited Warranty.
Transfer oil				0.31	5/8 pt	1/2 pt	Genuine NISSAN Differential Oil Hypoid Super-S GL-5 synthetic 75W-90 or equivalent
Differential gear oil				0.5	1 pt	7/8 pt	Genuine NISSAN HYPOID FLUID·S1 GL-5 75W-80 or equivalent
Coupling oil				0.58	1-1/4 pt	1 pt	Genuine NISSAN LSC Coupling Transmission Fluid 12-301 or equivalent.
Brake fluid				—	—	—	Genuine NISSAN Super Heavy Duty Brake Fluid or equivalent DOT 3 (US FMVSS No. 116) Available in mainland U.S.A. through a NISSAN dealer.
Multi-purpose grease				—	—	—	NLGI No. 2 (Lithium soap base)
Windshield washer fluid		For USA		2.4	2-1/2 qt	2-1/8 qt	Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent.
		For Canada		5.0	5-1/2 qt	4-3/8 qt
Air conditioning system refrigerant		USA production with Idle Start/Stop System		0.525 kg	1.16 lb	1.16 lb	HFO-1234yf (R-1234yf) For further information, see “Air conditioning specification label”.
		Japan production		0.550 kg	1.21 lb	1.21 lb
Air conditioning system oil				110 m	3.7 fl oz	3.9 fl oz	A/C System Oil ND-OIL12(PAG) or equivalent For further information, see “Air conditioning specification label”.

Engine Oil Recommendation

NISSAN recommends the use of an resource conserving oil in order to improve fuel economy.

Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide year-round anti-freeze and coolant protection. The anti-freeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary.

WARNING:

• Do not remove the radiator cap when the engine is hot. Serious burns could occur from high pressure engine coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by turning it all the way.

• The radiator is equipped with a pressure type radiator cap. To prevent engine damage, use only a genuine NISSAN radiator cap.

CAUTION:

• When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to -34°F (-37°C). If additional freeze protection is needed due to weather where you operate your Nissan Ariya vehicle, add Genuine NISSAN Long Life Antifreeze/Coolant (blue) concentrate following the directions on the container. If an equivalent coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) is used, follow the coolant manufactur's instructions to maintain minimum antifreeze protection to -34°F (-37°C). The use of other types of coolant solutions other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent may damage the engine cooling system.

• Mixing any other type of coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue), including Genuine NISSAN Long Life Antifreeze/Coolant (green), or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant.

Intercooler cooling system (if so equipped)

The intercooler cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide year-round anti-freeze and coolant protection. The antifreeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary.

WARNING:

• Never remove the radiator or coolant reservoir cap when the engine is hot. Wait until the engine cool down. Serious burns could be caused by high pressure fluid escaping from the radiator.

• The intercooler reservoir is equipped with a pressure type radiator cap. To prevent engine and intercooler damage, use only a genuine NISSAN intercooler reservoir cap.

CAUTION:

• When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to -34°F (-37°C). If additional freeze protection is needed due to weather where you operate your Nissan Ariya vehicle, add Genuine NISSAN Long Life Antifreeze/Coolant (blue) concentrate following the directions on the container. If an equivalent coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) is used, follow the coolant manufactur's instructions to maintain minimum antifreeze protection to -34°F (-37°C). The use of other types of coolant solutions other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent may damage the engine cooling system.

• Never use any additives in the coolant such as radiator sealer in the cooling system. This may cause damage to the intercooler.
