Hill start assist system
WARNING
|
When the vehicle is stopped on a hill, the hill start assist system automatically keeps the brakes applied.
This helps prevent the vehicle from rolling backward in the time it takes the driver to release the brake pedal and apply the accelerator.
Hill start assist will operate automatically under the following conditions:
The maximum holding time is two seconds. After two seconds the vehicle will begin to roll back and hill start assist will stop operating completely.
Hill start assist will not operate when the shift lever is shifted into N (Neutral) or P (Park) or on a flat and level road.
Preparation
Special Service Tools
The actual shapes of TechMate tools may differ from those of special service
tools illustrated here.
Tool number
(TechMate No.)
Tool name
Description
1. KV311039S0
( — )
Charging pipe set
2. KV31103920*
( — )
O-ring
CVT ...
The liftgate open warning continues displaying, or does
not display
Description
The liftgate open warning is displayed continuously even though the
liftgate is closed.
The liftgate open warning is not displayed even though the
liftgate is open.
Diagnosis Procedure
1.CHECK BCM INPUT SIGNAL
Check the BCM input signal. Refer to DLK-149, "Com ...
Connector Symbols
Most of connector symbols in wiring diagrams are shown from the terminal
side.
Connector symbols shown from the terminal side are enclosed by
a single line and followed by the direction mark.
Connector symbols shown from the harness side are enclosed by
a double line and foll ...
