Nissan Rogue (T33) 2021-Present Service Manual: Type B :: Preparation. Preparation

Nissan Rogue (T33) 2021-Present Service Manual / Driver Information & Multimedia :: Meter, Warning Lamp & Indicator / Type B :: Preparation. Preparation

Preparation

Commercial Service Tools

Tool name Description
Variable resistor

Check fuel gauge indication position
Power tool

Loosening screws
