Nissan Rogue (T33) 2021-Present Owner’s Manual & User Guide: BSW driving situations
Basic information
Indicator on
Indicator off
Indicator flashing
Illustration 1 — Approaching from behind
Another vehicle approaching from behind
Illustration 1: The side indicator light illuminates when a vehicle enters the detection zone from behind in an adjacent lane.
Illustration 2 — Approaching from behind
Illustration 2: If the driver activates the turn signal while a vehicle is in the detection zone, the system chimes twice and both the side indicator and BSW indicator flash.
NOTE:
- Vehicles approaching very quickly from behind may not always be detected.
- If the turn signal is activated before a vehicle enters the detection zone, indicators will flash but no chime will sound once the vehicle is detected.
Illustration 3 — Overtaking another vehicle
Overtaking another vehicle
Illustration 3: The side indicator light turns on if you overtake a vehicle and it remains in the detection zone for roughly 3 seconds.
Illustration 4 — Overtaking another vehicle
Illustration 4: If the turn signal is activated while a vehicle is in the detection zone, the system chimes twice and the indicators flash.
NOTE:
- When passing multiple vehicles in quick succession, those following closely may not be detected.
- Slower vehicles may not be detected if overtaken very rapidly.
- If the turn signal is activated before a vehicle enters the detection zone, indicators will flash without a chime.
Illustration 5 — Entering from the side
Entering from the side
Illustration 5: The side indicator illuminates if a vehicle enters the detection area from either side of your Nissan Rogue.
Illustration 6 — Entering from the side
Illustration 6: If the turn signal is activated while a vehicle is in the detection area, the system chimes twice and indicators flash.
NOTE:
- Vehicles moving at similar speeds may not always be detected when entering the zone.
- If the turn signal is activated before the vehicle enters the zone, only the flashing will occur, without a chime.
BSW system limitations
WARNING
Understanding the limitations of the Blind Spot Warning system is essential to avoid accidents or serious injury.
The Nissan Rogue BSW system cannot detect all vehicles under all conditions ...
System temporarily unavailable
If radar blockage is detected, the Blind Spot Warning system turns off automatically, a chime sounds, and the “Unavailable Side Radar Obstruction” message appears on the display.
The system remai ...
